DC SOLAR PUMP – 4 Inches Centrifugal Pump JCS4 Series

Description

1. Pump Controller
2. Impeller
3. Water Level Sensor
4. Cable for Solar Panel: 6m
5. Cable Connector

Outlet: stainless steel
Pump body: stainless steel
Motor Body: stainless steel
Impeller: stainless steel
Bearing: NSK

TYPE	VOLTAGE	POWER	MAX FLOW	MAX HEAD	OUTLET	DIAMETER
JCS4-5.0-28	24	250	5	28	1.25”	100
JCS4-6.0-40	48	500	6	40	1.25”	100
JCS4-6.0-52	48	600	6	52	1.25”	100
JCS4-7.5-34	48	750	7.5	34	1.25”	100
JCS4-5.5-60	48	750	5.5	60	1.25”	100
JCS4-5.0-128	72	1200	5	128	1.25”	100
JCS4-5.5-95	72	1000	5.5	95	1.25”	100
JCS4-6.7-88	72	1000	6.7	88	1.25”	100
JCS4-7.5-70	72	1000	7.5	70	1.25”	100
JCS4-6.5-98	72	1200	6.5	98	1.25”	100
JCS4-10-30	48	750	10	30	1.5”	100
JCS4-10-45	72	1000	10	45	1.5”	100
JCS4-15-21	72	1000	15	21	2”	100
JCS4-10-57	72	1200	10	57	1.5”	100
JCS4-15-28	72	1200	15	28	2”	100
JCS4-23-21	72	1200	23	21	2”	100
JCS4-22-32	220	1500	22	32	2”	100
JCS4-25-40	220	1800	25	40	2”	100
JCS4-25-54	288	2200	25	54	2”	100
JCS4-25-72	288	3000	25	72	2”	100
JCS4-25-96	288	4000	25	96	2”	100
